This official Yamaha IT175F parts manual provides comprehensive documentation for crankcase and cylinder components, essential for anyone maintaining, repairing, or restoring this classic motorcycle. The manual contains detailed part numbers, quantities, and specifications for all major crankcase assemblies, dowel pins, bolts, gaskets, drain plugs, nuts, spacers, O-rings, and absorber components. Each component is clearly identified with its corresponding Yamaha part number, making ordering replacement parts straightforward and accurate.
The documentation covers critical engine components including the main crankcase halves (parts 1W2-15111-02-00 and 1W2-15121-02-00), various dowel pins for proper alignment, socket head bolts of different lengths, gaskets for sealing, and mounting hardware. Additional components documented include engine mount spacers, O-rings for fluid sealing, and vibration absorbers that are crucial for proper engine operation and longevity.
This vintage parts manual is an invaluable resource for mechanics, collectors, and enthusiasts working on Yamaha IT175F motorcycles. The clear layout and official Yamaha part numbering system ensures you can confidently identify and source the correct components for your restoration or repair project. Whether you’re rebuilding the entire engine or simply need to replace specific crankcase components, this manual provides the authoritative reference you need.
